Model DV4001 User GuideDVD PlayerCLASS 1 LASER PRODUCTLUOKAN 1 LASERLAITEKLASS 1 LASERAPPARAT

Connecting Up210Connecting audio/video cablesBe sure to insert each plug fully for the best con nec tion. The plugs and jacks are color-cod ed to make

2Connecting Up11EnglishREMOTE CONTROLVer 1.0AUDIOLCOMPONENTBRYCCOAX.HDMIOUTINANALOGAC INRS-232CS1FLASHERINVIDEOCRA/V EUROCONNECTOR1432INT.EXT.Home the

Connecting Up212REMOTE CONTROLVer 1.0AUDIOLCOMPONENTBRYCCOAX.HDMIOUTINANALOGAC INRS-232CS1FLASHERINVIDEOCRA/V EUROCONNECTOR132INT.EXT.COAXConnecting a

3Controls & Displays13EnglishFront panel1 STANDBY indicator• Lights when the unit is in standby.2 Disc tray• Place the disc here.3 AU

Controls & Displays314Remote control1 AUDIO EX – Press to turn AUDIO EX off and on• The sound quality of analog audio output is improved by t

4Getting Started15EnglishPlaying discsThe basic playback controls for playing discs are cov ered here. Further func tions are detailed in the next cha

Getting Started416Navigating DVD disc menusMany DVD discs contain menus. Sometimes these are displayed automatically when you start playback; others o

5Playing Discs17EnglishIntroduction• Many of the functions covered in this chapter apply to DVD discs, Video CDs and CDs, although the exact operati

Playing Discs518• Use (2/3/5/∞) to select a track or use the numeric buttons to enter the selected track number.• To go to the previous or next p

5Playing Discs19EnglishFast Forward/Fast ReverseDVD-Video Video-CD CD MP3 WMAThe video images on DVD and VCD can be viewed as a Fast Forward and Fast

2CONGRATULATIONS ON YOUR PURCHASE OF THIS FINE MARANTZ PRODUCT.MARANTZ is on the leading edge of DVD research for consumer products and this unit inco

Playing Discs520Still Frame/Slow Play/Frame Advance PlaybackDVD-Video Video-CDThe video images on DVD and Video CD can be viewed as a still frame, pla

5Playing Discs21EnglishUsing the Repeat PlayDVD-Video Video-CD CD MP3 JPEG DivX WMAYo u can set the player to repeat individual tracks on CDs or Video

Playing Discs522Looping a section of a discDVD Video-CD CD MP3 DivX1 Press A-B once at the start of the section you want to repeat, then again at t

5Playing Discs23EnglishSwitching Camera AnglesDVD-VideoSome DVD-Video discs feature scenes shot from two or more angles. Check the disc box for detail

Playing Discs524Switching the Audio Language DVD-VideoWhen playing a DVD-Video disc recorded with dialog in two or more languages, you can switch the

5Playing Discs25EnglishPlay back InformationThis DVD system can display the disc playback information (for example, title or chapter number, elapsed p

Playing Discs526Angle1 Press 5/∞ to highlight “Angle”, then press ENTER to access.2 Use the numeric keypad (0-9) to enter in a valid number.3

5Playing Discs27EnglishPlaying an MP3/DivX/JPEG/ Windows Media™ Audio discThis DVD system can playback most of the MP3, JPEG and Windows Media™ Audio

Playing Discs528Playing a JPEG image fi le (slide show)• Insert a Picture disc (Kodak Picture CD, JPEG). For a Kodak disc, the slide show will be

5Playing Discs29EnglishPlaying MP3/WMA music and JPEG pictures simultaneouslyYo u can create a musical slide show if the disc contains both the MP3/WM

3EnglishIMPORTANT SAFETY INSTRUCTIONSREAD BEFORE OPERATING EQUIPMENT (for U. S. A only)This product was designed and manufactured to meet strict quali

Playing Discs530Playing a DivX discThis DVD system supports the playback of DivX movies which you can copy from your computer onto a CD-R/RW, DVD±R/±R

5Playing Discs31EnglishUsing the Setup MenuBefore using the player, you should specify the settings to be used in accordance with the conditions under

DVD Setup Menu632A black dot (z) in di cates the default setting* It can be set only during STOP.GENERAL SETUPAUDIO SETUPVIDEO SETUPPREFERENCE ENGLIS

6DVD Setup Menu33EnglishSetting up the GENERAL SETUP page1 Press the SETUP button.2 Select GENERAL SETUP PAGE using the cursor buttons (2/3), th

DVD Setup Menu634DISC LOCK• Default setting: UNLOCKNot all discs are rated or coded by the disc maker. You can prevent a specifi c disc from playing

6DVD Setup Menu35EnglishSetting up the AUDIO SETUP page1 Press the SETUP button.2 Select AUDIO SETUP PAGE using the cursor buttons (2/3), then p

DVD Setup Menu636LPCM OUT• Default setting: 48kHzIf you connect the DVD Player to a PCM compatible receiver via the digital terminals, such as coaxi

6DVD Setup Menu37EnglishSetting up the VIDEO SETUP page1 Press the SETUP button.2 Select VIDEO SETUP PAGE using the cursor buttons (2/3), then p

DVD Setup Menu638CANCELOKCHANGING PAL TO NTSC1.ENSURE THAT YOUR TV SYSTEM SUPPORTSNTSC STANDARD.2.IF THERE IS A DISTORTED PICTUREDISPLAYED ON THE TV.W

6DVD Setup Menu39EnglishCANCELOKCONFIRM AGAIN TO USE PROGRESSIVESCAN. IF PICTURE IS GOOD,PRESS OK BUTTON ON REMOTE.3) Press 2 to highlight OK in the

4WARRANTYFor warranty information, contact your local Marantz dis- trib u tor.RETAIN YOUR PURCHASE RECEIPTYour purchase receipt is your permanent reco

DVD Setup Menu640HDMI VIDEO• Default setting: AUTOSelects a suitable video resolution depending on the capability of the connected TV/device to enha

6DVD Setup Menu41EnglishDVI OUTPUT RANGE• Default setting: STANDARDWhen connecting the DVI unit, black may rise to the surface depending on the disp

DVD Setup Menu642Setting up the PREFERENCE page1 Press 7 (STOP) twice to stop playback (if any), then press SETUP.2 Select PREFERENCE PAGE using

6DVD Setup Menu43EnglishDISC MENUSelects the preferred disc menu language for DVD playback.• Default setting: ENGLISHUse the 5/∞ keys to select a la

DVD Setup Menu644Previewing VR format 1 During playback, press SCAN.2 Press 5/∞ to highlight either TITLE DIGEST or TITLE INTERVAL

6DVD Setup Menu45EnglishDEFAULTThis feature enables you to reset all the setup menu options and your personal settings to the factory defaults, except

Additional Information746Abkhazian 6566Afar 6565Afrikaans 6570Albanian 8381Amharic 6577Arabic 6582Armenian 7289Assamese 6583Avestan 6569Aymara 6589Aze

7Additional Information47EnglishHandling discsWhen holding discs of any type, take care not to leave fi ngerprints, dirt or scratches on the disc surfa

Additional Information748Hints on installationWe want you to enjoy using this unit for years to come, so please bear in mind the following points when

7Additional Information49EnglishSettings are canceled.• When the power is cut due to a power failure or by un plug ging the power cord, settings wi

5EnglishTable Of Contents1 Before You StartFeatures...6What’s in

Additional Information750The remote control doesn't seem to work.• The remote control is too far from the player, or the angle with the remote

7Additional Information51EnglishA disc containing the MP3 tracks won’t play.• If the disc is a recordable CD, make sure that the disc had been fi na

Additional Information752Specifi cationsGeneralSystemDVD-Video, DVD±R/RW, Video CD, CD, MP3 fi les, JPEG fi les, DviX and WMAPower requirements (U.S.A.).

7Additional Information53English

2006/09 PMC 00M20CW851250Printed in China

Before You Start16FeaturesAn HDCP-compatible HDMI*1 terminal is provided to ensure the very highest picture and digital sound quality by fully digital

1Before You Start7EnglishWhat’s in the boxThank you for buying this MARANTZ prod uct. Please confi rm that the following accessories are in the box whe

Before You Start18Discs compatible with this playerAny disc that displays one of the following logos should play in this player. Other formats, includ

1Before You Start9EnglishDVD-Video regions All DVD-Video discs carry a region mark on the case somewhere that indicates which region(s) of the world t
